MPS-9
TECHNICAL DATA
Axial pressure gauge
PG-P50A PG-I50A PG-S50A
PG-I50R PG-S60R
Radial pressure gauge
3-way connector Copper check valve
5-way connector Flexible hose
1.Pressure Range:20-60psi
2.Pressure Setting:20-40psi,30-50psi, 40-60psi
3.Rated Current 16(10)A
4.Rated Voltage: 11CA/-240V.380V
5.Frequency:50/60Hz
6.Max Ambient Temperature:50℃
7.Protection Degree:IP54
DESCRIPTIONS
1 .pressure switch used in water system
2. The switch start and stop the water pump
automaticafty according to the setting
pressure value.
3.One phase or three phase
